90° Wall Mount Support Bar

90° Wall Mount Support Bar

$97.50

The 90° Wall Mount Support Bar is designed to provide additional stability to fixed glass panels in shower enclosures or other similar installations. It can be mounted at a straight, 90-degree angle on a wall and is suitable for use with 5/16” (8 mm) to 1/2” (12 mm) thick glass panels.

This high-end support bar features a modern base design on the wall side and a U-shaped receptacle on the other end that can swivel to secure the fixed glass panel. Nylon-tipped set screws are included to help prevent glass-to-metal contact and securely hold the glass panel in place. It does not require any holes or cutouts in the glass to accommodate the support bar.

This product is a useful and stylish addition to any shower installation to obtain a full frameless look while keeping a good level of support.

Sold in length of 51” (1.3 m), to be cut to size on site. Screws and wall plastic anchors for installation are included in the kit.

Our shower hardware finishing process includes three different applied methods, each resulting in a durable, corrosion-resistant, and visually appealing finish. These methods include electrophoresis (Matte Black), chrome plating (chrome), and nickel plating (Brushed Nickel). Regardless of the chosen option, our hardware finish process guarantees a beautiful, long-lasting finish that meets the highest industry standards for quality and durability, providing exceptional performance and visual appeal.

THE KIT INCLUDES

Product SKU Qty
Support Bar Tube S-SB-TXX 1
Support Bar Bracket S-SB-UBXX 1
90 Wall Mount Support Bar Bracket S-SB-WM90XX 1

TECHNICAL SPECIFICATIONS

Safety Glass Thickness 5/16” (8 mm) to 1/2” (12 mm)
Color/Finish Chrome, Brushed Nickel, Matte Black
Manufacturing Material Stainless Steel



Finish

  • Chrome
  • Brushed Nickel
  • Matte Black
